Graco Husky 2150e 2" Electric Double Diaphragm Pump - 657464
SKU
657464
£22,560.00 £18,800.00
Overview
Stainless Steel Fluid Section, Stainless Steel Centre Section, Stainless Steel (316) Seats, PTFE Balls, PTFE Diaphragms, PTFE O-Rings
The Husky 2150e has a 2 inch (50.8 mm) connection and is available in Stainless Steel.
The Husky 2150e combine all of the benefits of a traditional air operated diaphragm pump like self-priming, stalling under pressure and increased diaphragm life with the benefits of an electric pump like energy cost savings, reduced pulsation and increased pump control.
Maximum Fluid Flow: | 142 gpm (537 l/min) |
Maximum Fluid Working Pressure: | 100 psi (6.9 bar, 0.69 MPa) |
Maximum Size Pumpable Solids: | 1/4 in (6.3 mm) |
Fluid Displacement Per Cycle: | 0.6 g (2.27 litres) |
Max. Flow Rate (l/min) | 537 |
---|---|
Max. Output Pressure (psi) | 100 |
Pump Inlet/ Outlet Size | 2" NPT(F) |
Max. Pump Speed | 160 cpm |
Compressor | No Compressor |
Motor Selection | ATEX AC Motor |
Fluid Section Material | Stainless Steel |
Centre Section Material | Stainless Steel |
Porting | Stainless Steel Standard Porting (BSPT) |
Seats | Stainless Steel (316) |
Balls | PTFE |
Diaphragms | PTFE |
Manifold O-Rings | PTFE |
Certification Required | ATEX |
